• 300Watt Continuous power output
  • Compliance with Intel SFX12V standard
  • DC to DC synchronous rectification design
  • Certified CB 62368-1
  • TUV, UL, cUL, CB, CE, FCC Safety & EMI approved
  • Typical 99% power efficiency by active PFC design
  • Support standard SFX , mini-ITX form factor
  • Support ATX and Micro-ATX via bracket (optional)
  • Dimension : 125(W) x 100(L) x 63.5(H)mm
  • Efficiency : 80PLUS (KT-S300FX-Ayy)
  • Cooling fan : Silent 80mm fan on top
  • Protection feature : OVP, OCP, OPP
  • Operating tmperature: 0-50 degree Celsius.
  • Storage temperature : -20-85 degree Celsius

 Output cable :



  • 20+4PIN
  • 12V P4+P4
  • SATA+mSATA
  • HDD 4P











More detailed information is available upon request

specification can be updated without notification
